Electronic Contactor for Equipment
Rating (* Type & Rating )
| Type | DMC20A | DMC25A | DMC32A | Rating DMC20C | Rating DMC25C | Rating DMC32C | |
|---|---|---|---|---|---|---|---|
| Poles(Pole) | 2 | 2 | 2 | 3 | 3 | 3 | |
| Rating Current(A) lth (A) | 30 | 40 | 50 | 30 | 40 | 50 | |
| Rating AC Level 3 Rating | AC220V | 20 | 25 | 30 | 20 | 25 | 30 |
| AC440V | 17 | 21 | 26 | 17 | 21 | 26 | |
| Maximum Applied Motor Capacity(Kw) | 1Ø110V | 0.9 | 1.2 | 2.2 | 0.9 | 1.2 | 2.2 |
| 1Ø220V | 1.8 | 2.2 | 5.5 | 1.8 | 2.2 | 5.5 | |
| 3Ø220V | 4 | 5.5 | 9.5 | 4 | 5.5 | 9.5 | |
| Standard Coil Voltage(VAC) | 24~550(10 types) | 24~550(10 types) | |||||
| Contact Composition | 2A | 3A, 2A1b | |||||
| Weight(kg) | 0.23 | 0.25 | |||||
| Download PDF Download DWG | Download PDF Download DWG | Download PDF Download DWG | Download PDF Download DWG | Download PDF Download DWG | Download PDF Download DWG | ||
Characteristic
- Power: Pump, motor, hoist, etc.
- Household electrical appliances: air conditioners, electric water heaters, hot air fans, etc.
- Vending machine: For control and power of vending machine
